| 型號 | ST Series |
|---|---|
| 間距 (mm) | 2.54 |
| PIN 數 | 01-50 |
| 料號 | STxx0xxAxxxxG |
Specifications
Materials Carrier : Brass Pin (outer sleeve) : Brass, machined, CuZn38Pb2 Clip(contact 4/6 finger) : Beryllium copper ,heat treated or PHBZ Plating(carrier) : Cu40~80u",Ni80~100u" Plating(outer sleeve) : Tin plated : 2um/80u"nickel,5um/200u"Tin Plating clip(contact): 2um/80u"nickel,gold or tin plating Electrical Current rating : 3 Amps/contact max. Contact resistance : ≦4mΩ /contact Mechanical Operating temperature : Gold plated: -55℃ to +125℃ (Continuous) -67℉ to +105℉ Tin plated: -40℃ to +105℃ Mechanical life : min.200
How to order
